Fast Search and Find My Keys/Wallet/Jewelry/Book/Document Device, Anti Lost Asset Location RFID UHF Tag Tracker, Cow/Sheep/Pet Animal Management System

1 / 5

Fast Search and Find My Keys/Wallet/Jewelry/Book/Document Device, Anti Lost Asset Location RFID UHF Tag Tracker, Cow/Sheep/Pet Animal Management System

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

Basic Info.

Model NO.

HC-SFS1.0

Certification

RoHS, ISO/TS16949, ISO14001, ISO2000, FCC, CE

Warranty

1 Year

Transport Package

1 System+150PCS Tracker

Specification

166mm(H)x79mm(W)x31mm(D)

Origin

China

HS Code

8471900090

Production Capacity

1000PCS/Day

Product Description

Overview

Before using our products, please read this manual carefully. It can better troubleshoot some faults for you and get a higher product experience.

Product Introduction

This product is an intelligent object-finding system designed based on RFID UHF technology. The application of this system is very extensive. It can be used in every family who has trouble finding things. it can also be used by small businesses that need to manage assets and items. Compared with some traditional search technologies such as Bluetooth, the technology we use has more advantages in tracker cost and ease of use. In terms of cost, the price of our system is a bit high, but once you have one system, you can use large number of trackers because the price of tracker is very cheap. And our tracker do not need power. Once our tracker is attached to the item, you no need to charge power for it, it will accompany the item permanently as a identification.

Core Functions

Locate items and find items
Inventory items and find missing items
Scan items and know what it is

Product Advantage

1 Higher positioning accuracy Traditional positioning technologies such as Bluetooth or GPS can only locate the items at a big area, like tell you this item is at home. However, our system can tell you item is in which cabinet and on which shelf at your home.

2 Tracker no need battery Our tracker no need battery. No matter Bluetooth or GPS, once power off then it lost function. But our tracker will never be power off, because it does not need battery.

3 Tracker is thin and small Our trackers are like paper sticker. You can put them on almost anything in your house.

4 Tracker is cheap Our smart finder system is little expensive, but our tracker is cheap. Once you have a system, then tracker is cheap for you. You can use any number of tracker without limitation.

Application Scenario

Families who have trouble finding items
Collectors who have many collections
Store
Leasing company
Small business manage asset
Small business manage warehouse
Researcher manage records
Farmers manage livestock
Pet shop manage animal
Factory manage machine parts or tools

Etc...

Product Parameter

ITEM	DESCRIPTION
Dimension	166mm(H)x79mm(W)x31mm(D)±2 mm (Not including the shield and pistol grip)
Weight	600g (including battery & wrist strap)
Display	Gorilla Glass 3 9H 5.5 in. TFT-LCD (720x1440) touch screen with backlight
Backlight	LED backlight
Expansions	1 PSAM, 1 SIM, 1 TF
Battery	3.8V, 9000mAh
CPU	Cortex A73 2.0GHz octa-core
Operating System	Android 9.0
Storage	2GB RAM/16GB ROM
Operating Temp	-20ºC to 50ºC
Storage Temp	-20ºC to 70ºC
Humidity	5%RH to 95%RH (non-condensing)
Drop Specifications	5ft./1.5 m drop to concrete across the operating temperature range
Protection Level	IP65, IEC compliance
ESD	±15kv air discharge, ±8kv direct discharge
RFID UHF Specifications	Impinj R2000 of main chip
	920MHz-925MHz of frequency
	Global EPC GEN2 ISO18000-6C protocol
	0-33dBm adjustable power, 3dBi Circular antenna
	0-25m scanning distance (Depends on tracker type)
Software	Smart Finder software.
Scanning Power & Distance	Add an item: 5dBm fixed, 0-20cm
	Scan items: 5dBm default, adjustable, 0-20cm when power is 5dBm. Scanning distance is up to 25m when power is 33dBm
	Searching: 33dBm fixed, detecting distance is up to 25m
	Inventory: 33dBm fixed, scanning distance is up to 25m
	Note: Reading distance is just for reference, it depends on many factors such as the type of tracker, the angle of detection, the material attached to the tracker, etc.

Frequently Asked Questions (FAQ)

How does this object-finding system locate items with high precision?

Unlike traditional technologies like GPS or Bluetooth which only locate items in a broad area (e.g., just telling you the item is inside your house), this RFID UHF system can pinpoint items down to the specific cabinet and shelf.

Do the item trackers require batteries or regular charging?

No, our trackers do not need batteries or power. Once they are attached to your items, they work permanently as an identification without the need for charging.

What is the scanning and reading distance of the trackers?

The system offers a scanning and detection range of up to 25 meters when operating at maximum power (33dBm). The actual reading distance depends on the tracker type, angle of detection, and the material of the attached item.

What are the dimensions and specifications of the main device?

The main device measures 166mm(H) x 79mm(W) x 31mm(D) ±2 mm (not including shield and grip) and weighs 600g (including battery & wrist strap). It is powered by a high-capacity 9000mAh battery and runs on Android 9.0.

How cost-effective is this system for managing a large number of items?

The system itself is a one-time investment. Once you have the main system, you can purchase and use an unlimited number of trackers at a very low cost, making it highly economical for extensive item tracking.
