The EC-BP-32 model of the EC-BP series is an emergency LED converter designed to ensure lighting continuity in the event of a power outage. It is the ideal solution for integrating LED lighting systems with an emergency function, combining reliability, compactness, and long life.
Emergency Power: 3.2W output with 6–54V SELV voltage range.
Selectable Duration: Configurable emergency autonomy for 1h, 2h, or 3h.
Advanced Battery Tech: Guaranteed autonomy with dedicated LiFePO4 batteries.
EMC Standards: EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3
The EC-BP-32 is perfect for emergency lighting applications in offices, commercial spaces, public, and industrial facilities, ensuring safety and operational continuity.
Specifications Table
Attributes
Value / Details
Brand Name
ACTEC
Type
Fire Emergency Light
Emergency Time
3 Hours
Warranty(Year)
2-Year
Input Voltage(V)
AC 220V( ± 10%)
Self Diagnostics
Yes
Lifespan (Hours)
10000
Operation
Remote Control
Light Source / Bulb Type
LED
Emitting Color
White
Color Temperature(CCT)
5000K (Daylight)
Color Rendering Index(Ra)
80
Lamp Luminous Efficiency(lm/w)
100
Control Method
Switch
Material
Plastic
Number Of Lamp Heads
1
Battery Type
Lead-Acid
Battery Capacity
2000 mAh
IP Rating
IP20
Support Dimmer
No
Application
Outdoor
Frequently Asked Questions
Q1: What is the main purpose of the EC-BP-32 emergency LED converter?
A1: The EC-BP-32 is designed to act as an emergency converter for LED systems. It guarantees lighting continuity during power outages, making it ideal for integration into commercial, public, and industrial offices.
Q2: How long can this converter supply backup power during an outage?
A2: The device features selectable emergency duration options, allowing you to configure the backup window for 1 hour, 2 hours, or 3 hours depending on your project needs and the connected battery capacity.
Q3: What safety protections are built into the system?
A3: It includes integrated temporary overheat protection, excessive battery discharge protection, and L-N / LN-PE 2kV overvoltage protection to ensure safe operation.
Q4: Does the converter support manual diagnostics and tests?
A4: Yes, the unit includes manual test capabilities and built-in self-diagnostic support to verify emergency operation status easily.
Q5: Which batteries are compatible with the EC-BP-32 model?
A5: It is compatible with dedicated LiFePO4 batteries configured for 3.2V at 3.3Ah (1h duration), 3.8Ah (2h duration), or 6.6Ah (3h duration).
Q6: What certifications and standards does this device comply with?
A6: The converter conforms to Safety standards EN 61347-1 and EN 61347-2-7, and EMC compliance standards EN 55015, EN 61547, EN 61000-3-2, and EN 61000-3-3.
